Brand
Fabricante SYSTIMAX Cód. GP Cabling 50494
NCM 85444200 CST Part. Nº CPC3312-03F007
Sob Consulta
Cotação por Peça

Sob Consulta

Documentos

DESCRIÇÃO

Dimensions
Cord Length, maximum 30 m | 100 ft
Cord Length, minimum 1 m | 1 ft

Electrical Specifications
ANSI/TIA Category 6
dc Resistance, maximum 0.30 ohm
Safety Voltage Rating 300 V

Environmental Specifications
Environmental Space Non­plenum
Flammability Rating UL 94 V­0
Operating Temperature ­10 °C to +60 °C (+14 °F to +140 °F)
Safety Standard Anatel | cETL | ETL

Mechanical Specifications
Conductor Type Stranded
Material Type Copper alloy | Polycarbonate
Outlet/Module Contact Plating Precious metals
Plug Insertion Life, minimum 750 times
Plug Retention Force, minimum 133 N | 30 lbf
Wiring T568B
